TT301 Motorised Tripod Turnstile for Reliable Pedestrian Access Control

The TT301 is a robust, high-quality tripod turnstile designed for reliable, general-purpose pedestrian access control. Its modular construction and flexible configuration options make it suitable for a wide range of indoor and outdoor environments.

Reliable performance

Configurable design

Enquire about TT301

Indoor & outdoor use

Where to buy

Why Choose the TT301?

Motorised Operation Without Manual Resetting

Manual turnstiles may require staff to physically lift the arm after a power failure or emergency release. The motorised drive mechanism supports automatic resetting when power is restored or the emergency condition returns to normal, reducing the need for manual intervention.

Reduced Mechanical Complexity - With fewer mechanical components than a conventional mechanical turnstile head, the design helps reduce mechanical complexity and wear.
Flexible Configuration - The modular design offers a choice of cabinet styles and finishes to suit different installation and appearance requirements.
Access-Control Integration - Compatible with most third-party access control systems, subject to interface requirements.

What version do we hold in UK stock?

The table below is a summary of the standard TT301 configuration we keep in UK stock. Additional configurations and options may be available to order — please contact us for details.

Need a different configuration?

The TT301 is available in a range of modular configurations. For full technical specifications, dimensions, electrical requirements and available options, see the TT301 Technical Datasheet or contact us to discuss your requirements.

Understanding the TT301

The TT301 is a motorised tripod turnstile designed to provide controlled pedestrian access in a range of environments. Its modular design, configurable operating modes and access-control integration make it a flexible solution for managed entrances.

Motorised three-arm mechanism
FREE, BARRED and CONTROLLED operating modes
Nine configurable operating modes
Emergency drop-arm operation
Automatic reset following power restoration or clearance of an emergency condition
Anti-crush protection
Modular cabinet, with bridged or boxed options
Indoor and outdoor installation
Throughput of approximately 15–25 people per minute

The TT301 motorised tripod turnstile is designed to manage pedestrian access across a range of commercial, public and managed-access environments. Its modular design and configurable operating modes support different entrance-control requirements. Potential applications include:

Sports facilities, stadiums and leisure centres.
Warehouses and factories.
Business parks and offices.
Healthcare facilities.
Schools, colleges and universities.
Public buildings, libraries, museums and exhibition centres.
Public toilet facilities.
Construction sites and research facilities.
Railway stations, bus stations, metro stations and airports.
Hotels.

The appropriate configuration depends on the site layout, expected pedestrian flow, access-control requirements and installation environment.

Access technical information and supporting documentation for the TT301 motorised tripod turnstile in our download area, including installation manuals and drawings. For further technical information or assistance selecting the right configuration for your project, please contact our team.

TT301 - Brochure

TT301 - Data Sheet

TT301 - O&M Manual

TT301 - Pictures and Videos

TT301 - Integrator Case Studies

TT301 - Presentations

The TT301 motorised tripod turnstile complies with BS EN 17352:2022 and incorporates safety features designed to address hazards associated with crushing, shearing, drawing-in, impact, trapping and imprisonment.

The emergency drop-arm function allows the arms to drop following a power failure or activation of the emergency input. The mechanism automatically resets when power is restored or the emergency condition clears.

Emergency release: Arms drop when the emergency input is activated.
Power failure: Arms drop when power is lost.
Automatic reset: Arms return to their normal position when power is restored or the emergency condition clears.

The TT301 motorised tripod turnstile provides controlled pedestrian access and integrates with compatible access-control systems. Each direction can be configured independently for free passage, restricted passage or authorised access:

Three operating modes: FREE, BARRED and CONTROLLED.
Access-control integration: Compatible with most third-party systems, including card readers, scanners and biometric devices, subject to interface compatibility.
Controlled passage: Uses a volt-free, normally open relay contact to trigger passage.
Bidirectional operation: Separate relay contacts are required for each direction when both directions are controlled.

Throughput is approximately 15–25 people per minute, depending on access-control response time and user behaviour.

Need help choosing the right solution?

Whether you need a quotation, CAD drawings, technical specifications or advice on selecting the right entrance control system, Evolve is here to help.

Our team provides product and technical guidance to help you and your systems integrator specify a solution that meets your security, operational and aesthetic requirements.

What is the TT301 tripod turnstile? The TT301 is a motorised tripod turnstile designed to manage pedestrian access through controlled entrances. It integrates with compatible access-control systems and offers configurable operating modes for different site requirements.

What are the dimensions of the TT301? The TT301 measures 1080 mm long × 240 mm wide × 980 mm high (length with thin ends) and weighs approximately 65 kg.

How many people can pass through the TT301 per minute? The TT301 has an approximate throughput of 15–25 people per minute. Actual performance depends on access-control response time and user behaviour.

Can the TT301 integrate with an existing access-control system? Yes. The TT301 is compatible with most third-party access-control systems, subject to interface requirements. Contact Evolve to confirm compatibility with your chosen equipment.

Can the TT301 operate in both directions? Yes. The TT301 can be configured for one-way or bidirectional operation, with separate control inputs for each direction where required.

What happens during a power failure or emergency? The turnstile arms drop when power is lost or the emergency input is activated. The mechanism automatically resets when power is restored or the emergency condition clears.

Can the TT301 be installed outdoors? Yes. The TT301 is suitable for indoor and outdoor installation. For outdoor installations, site conditions should be considered, and a canopy is recommended for user comfort.

Is the TT301 suitable for wheelchair access? No. A standard tripod turnstile does not provide a wheelchair-accessible passage. Where wheelchair access or a wider passage is required, a suitable alternative, such as the Evolve SG100 swing gate, should be provided alongside it.
