Accessible Swing and Pass Gates (SG)

Evolve SG swing and pass gates provide wide, controlled pedestrian access for wheelchair users, people with reduced mobility, pushchairs and users carrying larger items.

Designed for commercial buildings, retail, public facilities and other controlled entrances, the SG range combines accessible passage with reliable access control and smooth automatic operation.

✓ Wide Accessible Passage
✓ Access Control Integration
✓ Power-Assisted Operation
✓ Automatic Opening Options
✓ Suitable for Retail & Commercial Sites

Need an Accessible Entrance Solution?

Speak to our experts for tailored advice, competitive pricing, and the ideal DDA swing or pass gate for your building or facility.

Request a Quote

Speak to an Expert

Home >> Pedestrian>>Accessible Swing and Pass Gates

Why Choose Evolve SG Swing Gates

Evolve SG swing gates provide controlled pedestrian access through a wider passage, making them suitable for entrances where accessibility and ease of passage are important.

The power-assisted drive provides smooth, quiet operation, while the motorised design allows the gate to integrate with access-control systems and operate as part of a controlled entrance.

The SG range includes different configurations to suit a variety of environments, from corporate and commercial buildings to education, leisure, retail and public facilities.

Category: Accessible Swing Gates (SG)
Range: Swing Gates
Products: SG100, SG101, SG102, SG103, SGRetail

Accessible swing gate with transparent PMMA arms and two high-level detection sensors as standard.

SG100

Accessible swing gate with toughened glass arms and two high-level detection sensors as standard.

SG101

Accessible swing gate with transparent PMMA arms and higher glass cover.

SG102

Accessible swing gate with toughened glass arms and higher glass cover.

SG103

Retail swing gate with three high-level detection sensors as standard, designed for controlled one-way pedestrian flow and loss prevention.

SGRetail

Why Choose Evolve SGRetail

The SGRetail is specifically designed for retail and garden-centre environments where controlled pedestrian movement and loss prevention are important.

It can be installed at an entrance or exit to create a controlled one-way pedestrian route, helping manage customer flow while providing a practical alternative to conventional swing and pass gates.

The SGRetail is fitted with three high-level detection sensors as standard. Additional low-level detection sensors can be fitted where increased detection coverage is required, with lead-in and lead-out rails also available to improve tailgating and wrong-direction detection.

The SGRetail is also suitable for gyms, education and office environments where controlled pedestrian flow is required.

Understanding the SG Range

The SG range combines accessible pedestrian passage with controlled entrance operation. The sections below explain the security and safety features, key product characteristics, operation, typical applications and terminology used across the range.

The SG range provides wide, controlled pedestrian access with configurations to suit different accessibility, security and application requirements.

Key features include:

Wide accessible passage
Power-assisted motorised operation
Smooth and quiet operation
Access-control integration
Mechanical locking
Low impact force
Transparent PMMA or toughened glass arms, depending on model
Different glass-cover configurations
Automatic opening and closing
Detection sensors, depending on model
Single-direction operation for SGRetail
Additional detection and guide-rail options for SGRetail
Suitable for continuous-use environments

SG swing gates are suitable for entrances where accessible, controlled pedestrian passage is required.

Typical applications include:

Corporate offices and reception areas
Retail stores and garden centres
Gyms and leisure facilities
Schools, colleges and universities
Public buildings and facilities
Commercial buildings
Controlled emergency and escape routes
Entrances requiring wider access for wheelchair users, pushchairs or larger items

SGRetail is particularly suited to retail and garden-centre environments where controlled one-way pedestrian flow and loss prevention are important. It can also be used in gyms, education and office environments.

Swing Gate — A motorised pedestrian gate that opens by swinging the arm away from the passage.

Pass Gate — A wider pedestrian gate designed to provide controlled access for wheelchair users, people with reduced mobility and users carrying larger items.

Accessible Swing Gate — A swing gate designed to provide a wider, accessible passage through a controlled entrance.

Retail Gate — A pedestrian swing gate designed for retail environments, typically used to control entry and exit while supporting loss prevention and one-way pedestrian flow.

High-Level Detection Sensor — A sensor positioned at the upper part of the gate to detect pedestrian movement within its detection area.

Low-Level Detection Sensor — An additional sensor positioned lower on the gate to provide increased detection coverage.

SG swing gates incorporate safety features designed to support safe and controlled pedestrian movement.

SG100 and SG101 are fitted with two high-level detection sensors as standard. These support automatic closing and provide limited safety detection for users over 0.9 m. Because the sensors are positioned at high level, they do not provide full-height safety detection.

SG102 and SG103 use a higher glass cover, so the two high-level sensor arrangement used on SG100 and SG101 is not applicable.

SGRetail is fitted with three high-level detection sensors as standard. Additional low-level sensors can be specified where increased safety and detection coverage is required.

The SG range has a low impact force to help minimise the risk of injury during normal operation.

SG swing gates provide controlled pedestrian access while maintaining a wider, accessible passage.

The gates can integrate with a wide range of access-control systems and can be configured for controlled entry and exit.

SGRetail is specifically designed for controlled one-way pedestrian flow and loss prevention. It is fitted with three high-level detection sensors as standard, with optional low-level sensors and lead-in/lead-out rails available for increased detection coverage and improved tailgating and wrong-direction detection.

Security performance depends on the model, configuration and access-control system. Where a higher level of physical security is required, full-height turnstiles or security portals may be more appropriate.

SG swing gates use a motorised, power-assisted drive to provide smooth and controlled pedestrian passage.

Following an authorised access request, the gate opens to allow the user to pass and then returns to its closed position.

Detection sensors monitor pedestrian movement according to the model and configuration. SG100 and SG101 use two high-level sensors as standard, while SGRetail uses three high-level sensors and can be configured with additional low-level sensors.

SGRetail is designed for controlled one-way pedestrian flow and can be configured with lead-in and lead-out rails to support increased detection coverage.

What is an Accessible Swing Gate? An accessible swing gate is a motorised pedestrian entrance gate that provides a wider passage than a conventional turnstile or speed gate. It is designed to provide controlled access for wheelchair users, people with reduced mobility, parents with pushchairs and users carrying larger items.

Can Swing Gates integrate with access-control systems? Yes. SG swing gates can integrate with a wide range of access-control systems, including card readers, mobile credentials, QR and barcode readers, biometric devices and other access-control technologies, depending on the system configuration.

Are Swing Gates suitable for wheelchair users? Yes. The SG range provides a wider controlled passage designed to accommodate wheelchair users and people with reduced mobility. They can also provide easier access for pushchairs and users carrying larger items.

What is the difference between SG100, SG101, SG102 and SG103? The main differences are the arm material and glass-cover configuration. SG100 uses transparent PMMA arms with two high-level detection sensors as standard, while SG101 uses toughened glass arms with the same sensor arrangement. SG102 uses transparent PMMA arms with a higher glass cover, while SG103 uses toughened glass arms with a higher glass cover.

What is the difference between the SG range and SGRetail? The SG range is primarily designed to provide wide, accessible controlled pedestrian access. SGRetail is specifically designed for retail and similar environments where controlled one-way pedestrian flow and loss prevention are important. It can also be used in gyms, education and office environments where controlled pedestrian flow is required.

How do I choose the right Swing Gate? The right model depends on factors including passage width, accessibility requirements, arm material, glass-cover configuration, detection requirements, pedestrian flow and the intended application. The SG range includes configurations for accessible entrances, while SGRetail is designed for controlled one-way pedestrian flow and loss prevention.
